Product Description
This Vibratory Cup Mill model has 4 Grinding Bowls simultaneously clamped on the same platform. For samples that are sensitive to contamination in addition to various types of samples to be ground and analyzed simultaneously, we provide 2/3/4/5 bowl sets on one platform.
In this model 4 grinding bowls of 100 ml capacity can be loaded simultaneously.
Specification | Details |
Purpose | Pulverizing for Laboratory use. |
Pulverizing Material | Bauxite, Clinker and Raw mix, Coal, Coke, Concrete, Corundum, Geological ores, Glass, Granite, Graphite, Limestone, Iron ore, Quartz, Silicates, Slag, Ferro alloys. |
Working Principal | Friction and Impact. The vibratory cup mill is loaded with a Bowl set. Grinding is affected by heavy impact and friction. Sample is kept in the annular space between the bowl, the ring and the hammer after covering the top of the bowl. It is clamped on a vibratory platform, which imparts kinetic energy to the ring and the hammer. |
Feed Size | Fine to 5 mm |
Output Size | Up to 300 mesh, depending upon the time given for crushing/milling. |
Clamping | Manual. All bowls are clamped by one action, ensuring 100% safety. |
Display | Digital display to set time. Time Range: 0256 minutes. |
Safety Features | a) Door closing sensor provided. b) Over Load Relay (OLR) provided for motor safety. |
Motor | 1.5 KW, 2 HP, 415 V, 50 Hz, 3 Phase Induction Motor, 1440 RPM (Crompton / ABB). |
Required Power | 3 Phase with neutral + earthing, 10 Amps, 4 Pole MCB (to be provided by end user). |
Operation | Frequent ON/OFF or continuous operation for one hour. |
Mounting | The unit is floor mounting on leveled floor. No foundation required. |
Grinding Bowl Set
Elements/ Components: 1 each Bowl, Ring, Hammer, Lid and O-Seal
Capacity: 50 ml, 100 ml, 150 ml, 200 ml, 250 ml and 400 ml, (ring not required in 50 ml bowl)
Material of Construction: Hardened Steel / Tungsten Carbide Lined
Clamping: Quick and easy, no chance of slippage of bowl during run.
Leak Proof Grinding: The container when clamped with lid becomes 100% leak proof.
Effortless and Uniform Sample GrindingThe Vibratory Cup Mill VCM 4065 offers uniform and consistent grinding, ensuring materials reach the desired fineness efficiently. Its automatic operation reduces user effort, allowing for increased productivity in labs and industry. Mild steel construction boosts the equipment's endurance, while its voltage adaptability facilitates broad usage.
Reliable, Long-Lasting PerformanceBuilt with durability in mind, this grinding mill is equipped with a 1-year warranty, guaranteeing reliability for its users. Maintenance is straightforward, and the automatic functionality minimizes downtime during operations. Its reputation as a trustworthy product is maintained by top Indian exporters, manufacturers, service providers, and suppliers.
FAQ's of Vibratory Cup Mill - Grinding Mill VCM 4065:
Q: How does the Vibratory Cup Mill VCM 4065 operate to grind samples?
A: The VCM 4065 uses a vibratory motion to pulverize materials placed in its cup, achieving fine and uniform particle sizes quickly. Its automatic operation ensures consistency with minimal manual oversight.
Q: What types of materials can be processed using this grinding mill?
A: This mill is suitable for grinding a wide variety of solid samples, including minerals, ores, and other laboratory materials, thanks to its robust mild steel design and powerful mechanism.
Q: When should I consider using the VCM 4065 in my laboratory or industrial process?
A: You should use the VCM 4065 when precise, efficient, and repeatable grinding to fine powder is required, particularly for sample preparation prior to analysis or further processing.
Q: Where is the Vibratory Cup Mill VCM 4065 manufactured and exported from?
A: The VCM 4065 is manufactured and exported by leading companies in India, backed by their expertise as exporters, manufacturers, service providers, and suppliers.
Q: What is the standard process for operating and maintaining this grinding mill?
A: Operation involves loading the sample into the cup, setting the required parameters, and initiating the automatic grinding process. Maintenance generally includes regular cleaning and inspection, as per supplied guidelines, to ensure optimal performance.
Q: How does the lack of computerization affect usage of the VCM 4065?
A: Although not computerized, the VCM 4065's automatic functionality ensures straightforward and reliable operation, making it easy to use without needing complex programming or digital interfaces.
Q: What are the key benefits users receive from this model?
A: Users benefit from efficient and uniform grinding, adaptable voltage options, robust mild steel construction, ease of operation, and reliable after-sales support through a 1-year product warranty.
